Astrophotography by Anthony Ayiomamitis

Deep Sky Object Image Gallery

Open star clusters are widely distributed in our galaxy and represent a loose collection of stars which number from a few dozen to a few hundred stars and are weakly-held gravitationally. Perhaps the three most famous such open clusters are the Pleiades (M45) in Taurus, the Beehive (M44) in Cancer and the double cluster in Perseus. They are all characterized with a handful of hot and white prominent stars and nebular material surrounding these stars.

Note: The Dolidze-Dzimselejsvili open cluster catalog is comprised of eleven entries which are relatively unimpressive and generally dim with few member stars. Perhaps the most impressive entry is DoDz-9 in the constellation of Hercules which is both the largest and brightest catalog entry with an apparent diameter of 30'-35', a magnitude of 8.5 to 11 and comprised of 15 to 25 member stars.

Please click on the image below to display in higher resolution (1200 x 900)

Image Details
DoDz 9 - Open Cluster in Hercules
Imaging Details
NGC Number:
N/A

Common Name(s):
DoDz 9

Other Designations:
OCL 119, Lund 812

Object Type:
Open Cluster

Object Classif:
IV 3 m

Constellation:
Hercules

RA / Dec:
18h 08m 19s /
31° 36' 42"


Distance:
N/A

Object Size:
34' x 34'

Magnitude:
7.5 (est)
Date:
Jun 17-18, 2007
22:45 - 00:50 UT+3


Location:
Athens, Greece

Equipment:
AP 160 f/7.5 StarFire EDF
AP 1200GTO GEM
SBIG ST-2000XM
SBIG CFW10
SBIG LRGB + IR-block


Integrations:
Lum :  030 min (10 x 3 min)
Red :  030 min (05 x 6 min)
Green :  030 min (05 x 6 min)
Blue :  030 min (05 x 6 min)
Dark :  135 min (15 x 3+6 min)
Flat :  ~ 39,500 ADU
Binning :  1x1 (Lum),  1x1 (RGB)

Temperatures:
Ambient : + 27.8 ° C
CCD Chip : - 05.0 ° C

Software:
CCDSoft V5.00.182
CCDSharp V1.4
AIP4Win V2.1.19
Photoshop CS2
