Astrophotography by Anthony Ayiomamitis

Deep Sky Object Image Gallery

Open star clusters are widely distributed in our galaxy and represent a loose collection of stars which number from a few dozen to a few hundred stars and are weakly-held gravitationally. Perhaps the three most famous such open clusters are the Pleiades (M45) in Taurus, the Beehive (M44) in Cancer and the double cluster in Perseus. They are all characterized with a handful of hot and white prominent stars and nebular material surrounding these stars.

Note: Open cluster IC 4756 in Serpens depicted below is a rich open cluster comprised of about 100 member stars which are of varying brightness and is well detached from the background sky. The cluster spans 40 arc-minutes in diameter, lies at a distance of approximately 1,578 light-years away while spanning 15.2 light-years across and is dated at about 500 million years-old. The cluster is best observed using low magnifications (50-100x) during mid-summer as it approaches the southern meridian near midnight. IC 4756 was discovered by Harvard astronomer Solon I. Bailey while studying plates taken by a remote station in Peru. The cluster was also discovered independently by K. Graff in 1922 and which now bears his name.

Note: The image below was taken through thick humidity and will require a repeat visit.

Please click on the image below to display in higher resolution (1200 x 950)

Image Details
IC 4756 - Open Cluster in Serpens
Imaging Details
IC Number:
4756

Common Name(s):
Graff's Cluster

Other Designations:
Cr 386, Mel 210

Object Type:
Open Cluster

Object Classif:
II 3 r

Constellation:
Serpens

RA / Dec:
18h 39m 33s /
05° 27' 33"


Distance:
1,578 light-yrs

Object Size:
39'

Magnitude:
4.6
Date:
Aug 09-10, 2010
22:15 - 00:40 UT+3


Location:
Athens, Greece

Equipment:
AP 160 f/7.5 StarFire EDF
AP 1200GTO GEM
SBIG ST-10XME
SBIG CFW10
SBIG LRGB filters


Integrations:
Lum :  045 min (15 x 3 min)
Red :  030 min (05 x 6 min)
Green :  030 min (05 x 6 min)
Blue :  030 min (05 x 6 min)
Binning :  1x1 (Lum),  1x1 (RGB)

Image Scale:
1.16" per pixel

Temperatures:
Ambient : + 24.0 ° C
CCD Chip : - 10.0 ° C

Software:
CCDSoft V5.00.201
CCDStack V1.6.0.5
eXcalibrator V1.0.3.0
Aladin V6
Photoshop CS2
