Astrophotography by Anthony Ayiomamitis

Solar and Lunar Eclipse Image Gallery

Ever since man's first appearance on this planet, eclipses have been regarded as both mystical and devine with some cultures, for example, associating a lunar eclipse with the imminent arrival of death, war and/or famine. Although the distance of the moon and sun from earth vary dramatically (400,000 vs 150,000,000 km, respectively), the apparent size of these two heavenly bodies is such that they give the impression during an eclipse, solar or lunar, to be virtually identical (ie. about 30 arc-minutes in angular size). A total eclipse represents the unique occurrence in space and time where the sun, moon and earth are perfectly alligned as three collinear points on the same orbital plane. When the collinearity is not perfect but one of these three bodies is slightly higher or lower in the plane, we have a partial eclipse. Of course, a solar eclipse occurs when the moon lies perfectly between the sun and the earth, thus eclipsing the solar disk. In contrast, a lunar eclipse occurs when the earth lies between the sun and moon and, thus, the moon is hidden by the earth's shadow.

Note: Although total lunar eclipses are stunning events, partial eclipses involving the earth's penumbra and umbra are often considered non-events and not worthy of observation since the minute changes in the apparent magnitude of the moon are barely visible to the ground-based observer. However, as indicated by the image below (at eclipse maximum), even a partial eclipse can provide an impressive visual display.

Note: For a time series sequence with exposures spaced 30 minutes apart and centered on the eclipse maximum, click here.

Partial Lunar Eclipse: 2006-09-07/08
Stage
P-1
U-1
U-2
Max
U-3
U-4
P-4
Description
Penumbra
(First contact)
Umbra
(First contact)
Umbra Complete
(Start of Totality)
Maximum
Totality
Penumbra
(End of Totality)
Penumbra
(Full)
Penumbra
(End)
Time (UT+3)
19:42:23
21:05:03
N/A
21:51:21
N/A
22:37:41
00:00:20
Az / Alt
99.20 ° / -01.29 °
111.87 ° / +14.13 °
---.-- ° / +--.-- °
119.96 ° / +22.20 °
---.-- ° / +--.-- °
129.25 ° / +29.64 °
150.07 ° / +40.27 °

Image Details
Partial Lunar Eclipse: 2006-09-07/08
Imaging Details
Body:
Moon

Mass:
0.0123 x Earth

Mean Eq Diameter:
0.2719 x Earth

Distance:
357,291 km

Sidereal Rev:
27d 07h 43m 11s

Age:
14d 18h 31m

Diameter:
33.68'

Saros Cycle:
118

Magnitude:
Penumb+1.1579
Umbral+0.1897

Duration:
Penumb2h 08m 59s
Umbral2h 46m 19s
Date:
Sep 07, 2006
21:51:21 UT+3


Location:
Athens, Greece

Equipment:
AP 160 f/7.5 StarFire EDF
AP 1200GTO GEM
Canon EOS 300d


Exposure(s):
1 x 1/800 sec
ISO 400
RAW image format
3072x2048 image size
Manual Mode


Software:
Canon FileViewer V1.3.2
Photoshop CS-II


Processing:
RAW to TIFF (16-bit) Conv
Resampling
JPG Compression
