Astrophotography by Anthony Ayiomamitis

Lunar Image Gallery - S&T Lunar 100

In collaboration with Sky&Telescope Magazine, contributing editor and planetary scientist Charles Wood produced the "Lunar 100" list denoting perhaps the most interesting and instructive lunar features one may undertake in observing and/or imaging our closest celestial neighbour. The list is comprised of a wide variety of features and includes numerous craters (ex. L5 Copernicus, L6 Tycho), mountains (ex. L4 Appenines, L96 Leibnitz), rilles (ex. L29 Aridaeus, L66 Hadley), rays (L85 Langrenus, L93 Dyonisius), basins (ex. L59 Schiller-Zucchius, L73 Smythii) and domes (ex. L89 Valentine). Also, as one progresses sequentially through the list, features of increasing difficulty are encountered which, at times, may require favourable libration. In contrast to the Messier Catalog which may be pursued in its entirety in early spring during a single evening, the Lunar-100 will inevitably require a number of lunations for a complete enumeration from start to finish. Of course, the emphasis is not on how fast one may traverse the complete list but to gain a better understanding and appreciation of our moon and, thereby, our own planet's history.

Note: For further information on the Lunar-100, the interested lunatic is referred to S&T (Apr/2004: 113-120) and/or the analogue online reference available here.

Note: The photo below is available in inverted colour by moving your mouse over any portion of the same image.

Note: See S&T (Xxx/200x: 00-00) for further information in relation to the Serpentine Ridge.

Image Details
L033 - Serpentine Ridge
Imaging Details
List Item:
Serpentine Ridge

Quadrant:
N/E

Lunar Coordinates:
27.3° N 25.3° E

Length:
155 km

Height:
N/A

Lunation Age:
19d 08h 30m

Phase:
78.2°

Diameter:
30.87'

Magnitude:
-11.2

Rukl:
24

Date:
Oct 22, 2005
03:26 - 03:30 UT+3


Location:
Athens, Greece

Equipment:
AP 160 f/7.5 StarFire EDF
TeleVue 3X Barlow
Losmandy G-11 GEM
Philips ToUCam PCVC 740k
Baader UV/IR-Cut Filter (1.25")


Video Imaging:
1 AVI @ 10 fps (2400 frames)
Frame Rate : 10 fps
Exposure : 1/25 sec
Brightness : 50%
Contrast : 50%
Gamma : 50%
Saturation : 50%
Gain : 50%
Mode : RGB

Software:
K3CCDTools V2.4.9.895
HandyAVI V1.7
Registax V2.1.0.0
Photoshop CS-II


Processing:
Selective Sampling (140/2400)
Registration & Alignment
Average Combine
RGB to Monochrome
JPG Compression
