Astrophotography by Anthony Ayiomamitis

Lunar Occultation Image Gallery

Although occultations can occur in a variety of ways, the heavenly body most often involved is our moon which inevitably will occult (or eclipse) background stars, other planets as well as asteroids. The study of occultations is important, for example, for the study of the moon's limb and its profile thanks to the grazing of lunar features such as mountains.

What is perhaps more interesting but not as frequent is occultations involving the moon and one of the planets. Typically the planets involved are Venus, Mars, Jupiter and Saturn. Due to the great magnitude difference between the moon (any phase) and any of these planets, the photography of these events can be challenging.

Without doubt, the most stunning example of the Moon occulting another body is that involving the Sun which, of course, leads to a solar eclipse. This special example of an occultation is available elsewhere on this site.

Note: Venus is only second to the Moon when it comes to the brightest object visible in the evening sky and, in fact, is also visible during the day naked-eye when sufficiently away from the Sun. For this particular occultation involving the Moon and Venus, the waxing 2.7-day old crescent Moon was at magnitude -7.2 with a phase of 9.3%, an apparent diameter of 32.1 arc-mins and a solar elongation of 35.5 degrees whereas Venus was characterized with an apparent diameter of 13.40 arc-seconds, a magnitude of -4.0 and a phase of 79.7.0%.

Note: The human eye has a tendency to focus at a distance of 400 feet when focusing for "infinity". As a result, many celestial objects which are visible during the day can become a challenge due to the eye's default focusing for infinity. When the moon is near a celestial object of interest, however, the eye will easily focus properly for "infinity" when looking at the moon and which in turn will permit for the easy identification of the (neighbouring) celestial object of interest such as Venus below in broad daylight (upper left corner of the image below).

Note: For previous occultations involving the Moon and Venus from 2004, 2007 and 2010, click here.


Image Details
Selene and Aphrodite (2023)
Imaging Details
Body:
Venus

Mean Distance (A.U.):
0.723

Equatorial Diam (km):
12,104

Mass:
0.82 x Earth

Volume:
0.86 x Earth

Orbital Period:
224.701 days

Number of Moons:
0

Orbital Eccentricity:
0.007

Orbital Inclination:
3.4°

Albedo:
0.65
Date:
Mar 24, 2023
12:52:47 UT+2


Location:
Athens, Greece

Equipment:
AP 160 f/7.5 StarFire EDF
AP 1200GTO/CP3 GEM
Canon EOS 6D Mk I
Baader UV/IR-Cut Filter


Exposure:
1 x 1/640 sec
ISO 100
RAW Image Format
5472x3648 Image Size
Manual Mode
Continuous Servo Mode


Software:
Digital Photo Pro V4.6.30.0
Photoshop CS6


Processing:
RAW to TIFF (16-bit) Conv
Resampling
JPG Compression
