Astrophotography by Anthony Ayiomamitis

Lunar Image Gallery - Rupes

Of the eight lunar features identified as rupes or scarp, perhaps the two most dominant are Rupes Altai and Rupes Recta. The image of Rupes Altai below was taken near the terminator of a nineteen-day old moon and features very good detail surrounding the scarp including fine-level detail within the 427-km long scarp itself. This formation lies to the west of Mare Nectaris and is believed to be between 3.82 and 3.95 billion years old. Its northern-most point is around the well-known crater Catharina and its termination point is just before crater Piccolomini.

Note: Further information in relation to Rupes Altai is available in S&T (Jun/2004: 68-69).

Image Details
Rupes Altai
Imaging Details
Feature Item:
Altai Scarp

Quadrant:
S/E

Lunar Coordinates:
24.3° S 22.6° E

Length:
427.0 km

Height:
3.5 - 4.0 km

Lunation Age:
19d 01h 11m

Phase:
80.7°

Diameter:
30.36'

Magnitude:
-11.3

Rukl:
57
Date:
Oct 03, 2004 @ 02:31:42 UT+3

Location:
Athens, Greece

Equipment:
Celestron 14" SCT
Celestron f/6.3 reducer
Losmandy G-11 GEM
Philips ToUCam PCVC 740k


Video Imaging:
1 AVI (1307 frames)
Frame Rate : 5 fps
Exposure : 1/250 sec
Brightness : 50%
Contrast : 50%
Gamma : 00%
Saturation : 50%
Gain : 10%
Mode : B&W

Software:
K3CCDTools V1.0.6.460
Registax V2.1.0.0
Photoshop V6


Processing:
Registration
Selective Sampling (1255/1307)
Alignment
Average Combine
JPG Compression
