Astrophotography by Anthony Ayiomamitis

Solar System Image Gallery - Dwarf Planets

Following the general meeting of the IAU in 2006, a new classification scheme was released for the various members of the solar system and which was inspired by the 2003 discovery of Eris, a Kuiper belt object beyond the orbit of Pluto and which happened to be also larger than Pluto by about 100 km. To be more specific, the three categories adopted where (1) planets, (2) dwarf planets and (3) small solar system bodies.

Dwarf planets are similar to planets in the sense they orbit the sun and have sufficient mass so that gravitational forces lead to a generally round shape but which have failed to clear their orbit of debris due to a lack of a dominating gravity. Using this definition, the solar system is now characterized with eight (and not nine) planets, five dwarf planets (Pluto, Ceres, Iris, Makemake and Haumea) and various small solar system bodies excluding satellites.

Three members of the asteroid belt (Vesta, Pallas, Hygieia) as well as over 40 trans-Neptunian objects (Orcus, Ixion, Huya, Varuna, Quaoar, Sedna etc) are believed to eventually be classified as dwarf planets.

Note: Pluto has a history similar to that of Neptune in that it was discovered in 1930 by Clyde Tombaugh following calculations by Percival Lowell. Pluto is quite unique in that it is smaller than our moon, has a "large" moon (Charon) whose diameter is more than half of the parent planet and a very eccentric orbit which brings it inside Neptune's orbit at perihelion. Observation of Pluto is only possible with a telescope due to its very low (14th) magnitude. For an ephemeris of Pluto using the facilities of the Jet Propulsion Laboratory (NASA), click here. Similarly, for Pluto's orbital elements, click here.

Note: The field of view in the image below involves the twin Barnard dark nebulae B92 and B93 and where Pluto happened to be traversing through in the summer of 2010.

Please click on the image below to display in higher resolution (1200 x 850)

Image Details
Dwarf Planet Pluto
Imaging Details
Dwarf Planet:
Pluto

Alt Designation:
Asteroid 134340 Pluto

Aphelion:
49.305 A.U.

Perihelion:
29.658 A.U.

Dimensions:
~1153 km

Orbital Period:
248.5 yr

Number of Moons:
3

Orbital Eccentricity:
0.250

Orbital Inclination:
17.1°

Albedo:
0.30

Magnitude:
14.0
Date:
Jul 06, 2010
00:25 - 01:30 UT+3


Location:
Athens, Greece

Equipment:
AP 160 f/7.5 StarFire EDF
AP 1200GTO GEM
SBIG ST-10XME
SBIG CFW10
SBIG LRGB filters


Integrations:
Lum :  60 min (20 x 03 min)
Red :  N/A
Green :  N/A
Blue :  N/A
Binning :  1x1 (Lum),  1x1 (RGB)

Image Scale:
1.17" per pixel

Temperatures:
Ambient : + 24.0 ° C
CCD Chip : - 12.5 ° C

Software:
CCDSoft V5.00.195
CCDStack V1.6.0.5
Photoshop CS2
