Solar Image Gallery - Rainbows

One of the most impressive light shows that one can experience from the surface of the earth is that involving the ionization of particles in the atmosphere and which leads to the "dancing lights" commonly referred to as Aurora Borealis and Aurora Australis (see here). Perhaps an equally impressive light show and probably more frequent, certainly in the Meditteranean, is the rainbow which graces the sky with a dramatic refraction pattern of the white light spectrum.

More specifically, when solar sunlight encounters water droplets, it is partitioned into its constituent spectral colors and dispersed back to the ground observer. This phenomenon, commonly studied in optics and described as early as 1637 by Rene Descartes, has several interesting features including a set of circular colored arcs in the form of parallel bows with a common center; the sun is immediately behind the observer facing the rainbow; and the center of the arcs are precisely 180° away from the associated light source (the sun). Furthermore, the angle between the incident ray of light entering the water drop(s) and that redirected back to the observer (resultant ray) varies between 40° and 42° and, hence, accounts for the observed spectral pattern (blue has the least refraction angle at 40° whereas red the greatest at an angle of 42° with the balance of the colors lying between these two extrema).

Finally, the location of the sun during this refraction process determines the size of the rainbow arcs. When the sun is low to the horizon (ex. around sunset), the rainbow arcs are very large and can approach the size of a semi-circle. In contrast, when the sun is very high, these arcs are much smaller. On very rare occasions, the incident ray of sunlight will be reflected a second time within the rain drop and thus lead to a resultant exit ray which is not between 40° and 42° but one between 52° and 53° and, thus, yield a further and secondary rainbow which coincidentally has its color sequence in reverse to that of the primary rainbow.

Note: While preparing the telescope equipment the evening prior to the Venus transit against the solar disk (click here), a brief but strong storm passed through the Athens region. A few minutes following the passage of the storm, the very rare double rainbow illustrated below was observed with the sun being only a few degrees above the horizon and about to set.


Image Details
Rainbow Twins at Sunset
Imaging Details
Body:
Sun

Mass:
332,900 x Earth

Mean Eq Diameter:
109.1 x Earth

Distance:
152 million km

RA / Dec:
05h 04m 37s /
22° 49' 43"


Diameter:
32.37'

Magnitude:
-26.8

Light Time:
0h 8m 21.6s
Date:
Jun 07, 2004
20:37:27 UT+3


Location:
Athens, Greece

Equipment:
Canon EOS 300d
Canon EOS EF-S 18-55 mm
     @ 40 mm


Exposures:
1 x 1/125 sec @ f8.0
ISO 800
RAW Image Format
3072x2048 Image Size
Manual Mode


Software:
Canon FileViewer V1.3.2
Photoshop V6


Processing:
RAW to TIFF (16-bit) Conv
Resampling
JPG Compression
