Astrophotography by Anthony Ayiomamitis

Solar Image Gallery - Sunspots

Perhaps the most obvious feature of the Sun is the sunspots that characterize the photosphere. The base temperature of the 300-km deep photosphere is approximately 6400 °C whereas the sunspot regions are characterized with areas of relatively lower temperature (around 4800 °C for the umbral regions and 5900 °C for the penumbral regions) and increased magnetic activity (up to 3000 times the average magnetic field of the Sun). Due to the differential rate of rotation of the solar disk (26 days at the equator and 36 days at the poles), there is a "twisting" of the magnetic fields which surface to the photosphere producing sunspots. Typically, these spots and groups are found to lie + 30° of the solar equator and can physically be many-fold times larger than our planet! As the images below indicate, sunspots are characterized with a dark core, the "umbra", where the temperature is about 1600 °C less than the surrounding temperature of the photosphere whereas the less darker envelope which typically encompasses the umbral region, the "penumbra", is about only 500 °C less than the surrounding photospheric temperature.

Studies have shown sunsplot activity to exhibit an eleven-yr cycle with virtually little sunspot activity during the minima of the cycle whereas frequent sunspots and associated groups dominate during the maximum of the same cycle, typically approximately 4.5 years after the minimum. During the solar maximum, we also have frequent filaments, flares and prominences (see here) which include ejected material from the Sun's outermost "shell", the chromosphere, that reaches Earth causing, for example, geomagnetic storms that produce the well-known and beautiful aurora borealis and australis.

Note: The Sun on Christmas Day (2023) is dominated by various sunspot groups led by AR 3531 (Zurich class: Hax, 20° S, 16° E) and AR 3529 (Zurich class: Eho, 21° S, 25° W). The other prominent groups visible in the image below are AR 3533 (Zurich class: Cri, 15° N, 16° E), AR 3530 (Zurich class: Dai, 08° N, 06° W), AR 3526 (Zurich class: Cao, 14° N, 22° W), AR 3521 (Zurich class: Hrx, 11° N, 50° W) and AR 3528 (Zurich class: Dao, 08° N, 68° W).

Image Details
Solar Active Regions 3521 - 3533
Imaging Details
Body:
Sun

Mass:
332,900 x Earth

Mean Eq Diameter:
109.1 x Earth

Distance:
147.1 million km

RA / Dec:
18h 15m 19s /
-23° 23' 37"


Diameter:
32.52'

Magnitude:
-26.8

Light Time:
0h 8m 27.3s
Date:
Dec 25, 2023
12:51:32 UT+2


Location:
Athens, Greece

Equipment:
AP 160 f/7.5 StarFire EDF
AP1200GTO/CP3 GEM
AP 2x Conv Barlow
Canon EOS 6D Mark I
Baader UV-IR/Cut
Baader ND-5 (full-aperture)


Exposure:
1 x 1/2000 sec
ISO 1000
JPG Image Format
5472x3648 Image Size
Manual Mode


Software:
Photoshop CS6

Processing:
Grayscale
Unsharp Masking
Brightness/Contrast
Levels
Resampling
JPG Compression
