Star Trail Image Gallery

One of the most basic types of astrophotography and yet equally stunning is that involving star trails, particularly around the celestial poles or immediately due east or west. In addition to capturing the motion of stars around the north pole which are circumpolar and, hence, never rise or set, we also have the ability to capture seasonal constellations and stars in such photos, thus allowing for different opportunities during different seasons. Star trail photos also provide direct evidence that our planet rotates and does so at a rate of 15° per hour. Furthermore, by studying the arc for a particular star, especially as far away from the pole as possible, one can indirectly estimate the length of the (total) exposure which often ranges from seven to eight hours in duration and is totally dependent on the end of astronomical twilight one evening and its onset the following morning.

Many star photos are centered on Polaris, a double star system which represents our quickest means to locating the north celestial pole, for it lies less than 1.0° from it, and is an excellent starting point for the polar alignment of a telescope (and finding your way home if you are lost!). Due to the extended length of the typical exposures involved, the best film for such work is Kodak Elite Chrome (ISO 100) whose reciprocity failure is nearly zero or Fujichrome Velvia and Provia (ISO 50 and 100) emulsions with equally impressive curves! With respect to equipment, it is rudimentary, for a camera with extended exposure capibility is required along with a firm tripod and shutter release and locking cable. It is also preferable that the camera used have a mechanical shutter so that battery consumption and power does not become an issue during mid-exposure. The final requirement is a location with dark skies - the darker the better so that the trails and their colouration will be as bright and contrasty as possible - with, preferably, an interesting foreground which can be used to enrich the final result.

Note: Mount Dirfys (or Dirfy) is the tallest mountain in Euvoia and is only second to the taller mountains of Crete amongst all the greek islands. The absolute peak, "Delphi", is at 1743 meters and is often characterized with snow cover due to cool northeastern jet streams which pass over the mountain. The eastern side of the mountain is quite abrupt whereas the western side is conical in shape. The mountain is characterized with rich vegetation and plants including a plethora of evergreens, chestnut and oak trees as well as sycamores and pines with rich water flows helping a bustling bottled water industry. Mt Dirfy is a popular choice for mountain climbers and includes a refuge center at 1100 meters (see right side of the photo below).

Image Details
Star Trails Over Mount Dirfys
Imaging Details
Proper Star Name:
Polaris

Bayer Letter:
á Ursae Minoris

Tycho Catalog:
TYC 4628-237-1

SAO Catalog:
SAO 308

Luminosity
2290 +/- 282 x Sun

Distance:
431 +/- 26 light yrs

RA / Dec:
02h 39m 31s /
+89° 17' 39"


B-V Color Index:
+0.570 mag

Magnitude:
1.98
Date:
Jul 12-13, 2015
22:40 - 01:36 UT+3


Location:
Mount Dirfys
Euvoia, Greece


Equipment:
Canon EOS 5D Mk I
Canon EOS EF 15mm/f2.8 @ f4.0


Exposures:
176 min (088 x 120 sec) (RGB)
020 min (010 x 120 sec) (Dark)
ISO 500
JPG Fine Image Format
4368x2912 Image Size
Continuous Servo Mode


Software:
Startrails V2.3
Photoshop CS5


Processing:
Dark Frame Reduction
Layers and Lighten
Resampling
Unsharp Masking
JPG Compression
